✅ Key Features:
-
Double-walled construction with high-efficiency 80mm PUF insulation
-
Inner chamber made from 18 SWG AISI 304 stainless steel, mirror-polished for corrosion resistance
-
Durable CRCA outer body with epoxy powder coating
-
Lockable castor wheels for easy mobility
-
Dual metallic doors with magnetic gaskets and secure locking system
-
Efficient heating system using U-shaped oxidized Nichrome air tubular heaters
-
CFC-free refrigeration system with Emerson hermetically sealed compressor
-
Rear-side dynamically balanced air circulation ensures temperature uniformity
-
Microprocessor-based PID controller with dual digital display (Set & Process value)
-
PT-100 RTD sensor with 0.1°C resolution and feather-touch control panel
🌡️ Temperature Range:
Ambient to –10°C / +1°C
📐 Chamber Dimensions:
300mm (W) x 300mm (H) x 5000mm (L)
Total Volume: 475 Litres
⚙️ Technical Specifications:
| Feature | Specification |
|---|---|
| Inner Chamber | 18 SWG AISI 304 Stainless Steel, Mirror Finish |
| Outer Body | 18 SWG CRCA Sheet, Epoxy Powder Coated |
| Insulation | 80mm Thick High-Density PUF |
| Heating System | Easily Replaceable ‘U’ Shape Nichrome Air Tubular Heater |
| Cooling System | Hermetically Sealed CFC-Free Emerson Compressor |
| Air Circulation | Rear-mounted motorized blower system |
| Controller | PID Microprocessor with Set & Process Display, PT-100 Sensor |
| Mobility | Mounted on Heavy-Duty Lockable Castors |
| Power Supply | 230V ±10%, 1 Phase, 50 Hz |
Applications:
-
Conduit Mechanical Testing
-
Thermal Stress Testing for Electrical Ducts
-
Environmental Simulation for Material Performance
