✅ Key Features:
-
Triple-walled construction with high-grade thermal insulation
-
Available in Regular and GMP-compliant models
-
Uniform heat distribution via side-mounted heating elements
-
Capacitor-run blower motor ensures efficient air circulation
-
Microprocessor-based PID temperature controller with PT-100 sensor
-
Flush-type door with positive locking mechanism
-
Ventilators provided on top and side for effective exhaust
📐 Working Sizes Available:
-
45 x 45 x 45 cm
-
60 x 60 x 60 cm
-
60 x 60 x 90 cm
🌡️ Temperature Range Options:
-
Ambient to 250°C
-
Ambient to 300°C
-
Ambient to 400°C
⚙️ Technical Specifications:
| Feature | Specification |
|---|---|
| Construction | Triple-walled (Regular & GMP models) |
| Air Circulation | Side-mounted blower with heavy-duty motor |
| Heating Elements | Dual-side mounted for uniform heat |
| Controller Type | PID Microprocessor-based with PT-100 sensor |
| Ventilation | Provided on top and side |
| Door Type | Flush type with positive lock |
| Power Supply | 230 V AC, 1 Phase, 50 Hz |
Applications:
-
Pharmaceuticals: Drying glassware, thermal stability tests
-
Research Laboratories: Incubation, sterilization, tempering
-
Food & Beverage: Thermal storage and dehydration
-
Chemical & Industrial: Heat treatment and material testing
