✅Key Features:
-
Double-walled heavy-duty construction for superior thermal efficiency
-
Inner chamber in stainless steel, outer body powder-coated for corrosion resistance
-
Mounted on lockable castors for easy movement and stability
-
Heavy-duty trays with a load capacity of up to 70 kg
-
40mm diameter porthole for internal observation without heat loss
-
Powerful blower system for uniform air circulation from the side
-
Dual-side heating elements ensure even heat distribution
-
Fully automatic microprocessor-based PID controller
-
Equipped with high-accuracy PT-100 RTD sensor
🌡️ Temperature Range:
Ambient to 150°C with precise control
📐 Chamber Dimensions:
Internal Size: 1100 mm (L) x 700 mm (D) x 1100 mm (H)
Total Volume: ~850 Litres
⚙️ Technical Specifications:
| Feature | Specification |
|---|---|
| Construction | Double-walled, SS inner chamber, powder-coated outer body |
| Mobility | Lockable castor wheels for easy transportation |
| Tray Capacity | Heavy-duty trays, 70 kg load capacity |
| Air Circulation | Capacitor-run motor with side-mounted blower |
| Heating System | Side-mounted heating elements for even heat distribution |
| Temperature Control | PID microprocessor-based controller with PT-100 RTD sensor |
| Port Hole | 40mm diameter, ideal for sensor/probe insertion |
| Power Supply | 230V ±10%, 1 Phase, 50 Hz |
Applications:
-
Laboratory & Industrial drying and heat treatment
-
Sample incubation and thermal conditioning
-
Moisture removal from equipment or components
-
Suitable for chemical, pharmaceutical, and electronics industries
