Key Features
-
Cylinder Capacity: Standard 2000 ml with bottom outlet for easy drainage.
-
High-Capacity Circulating Pump: Ensures continuous fluid recirculation.
-
Flow Rate: Minimum 8 L/min with precise control.
-
Digital Flow Meter: Accurate flow measurement up to 8 L/min.
-
Nozzle Design: 8 mm inner diameter at inlet and 5 mm at outlet for controlled liquid flow.
-
Flow Regulator: Valve-controlled adjustment for precise testing.
-
Time Totalizer: 99999.99 hours for long-duration test monitoring.
-
Continuous Operation: Capable of running non-stop for 24 hours.
-
Power Supply: 230 V ±10%, Single Phase, 50 Hz.
Construction Details
-
Transparent flexible tubing for easy observation.
-
Rugged build for industrial and laboratory use.
-
Designed to meet CNOMO and industrial testing standards.
Applications
-
Foam testing in lubricants, oils, and emulsions.
-
Quality control in oil and lubricant industries.
-
Research and development of anti-foam additives.
Technical Specifications:
-
Cylinder: 2000 ml with bottom outlet
-
Pump: High-capacity recirculating pump
-
Flow Rate: 8 L/min
-
Flow Meter: Digital, up to 8 L/min
-
Nozzle Size: 8 mm (inlet), 5 mm (outlet)
-
Timer: Up to 99999.99 hours
-
Power Supply: 230 V ±10%, 1 Phase, 50 Hz
