Key Features:
-
✅ Designed for accurate kinematic viscosity measurement using calibrated capillary viscometers
-
✅ Double-walled rectangular bath with toughened glass observation window (254 W x 225 H mm)
-
✅ Rear illumination system ensures clear visibility for reading fluid levels
-
✅ Oil immersion heater provides efficient and uniform temperature control
-
✅ Microprocessor-based PID temperature controller with PT-100 sensor and digital display
-
✅ Temperature accuracy of ±0.02°C with 0.1°C resolution
-
✅ Bath size: 254 x 200 mm with cover, holds 6 viscometers using 6 Bakelite holders
-
✅ 22-litre bath capacity
-
✅ Efficient magnetic stirring system ensures uniform thermal distribution
-
✅ Operates at standard viscosity test temperatures: 40°C & 100°C
-
✅ Power Supply: 230 V AC, 1 Phase, 50 Hz
⚙️ Technical Specifications:
| Parameter | Specification |
|---|---|
| Temperature Range | 40°C & 100°C |
| Temperature Accuracy | ±0.02°C |
| Resolution | 0.1°C |
| Construction | Double-walled with toughened glass window |
| Bath Opening | 254 x 200 mm with six 50 mm viscometer ports |
| Liquid Capacity | 22 Litres |
| Stirring System | Efficient, uniform magnetic stirrer |
| Heater Type | Oil immersion heater |
| Controller | PID microprocessor-based with PT-100 sensor |
| Power Supply | 230 V, 1 Phase, 50 Hz |
🧪 Applications:
-
Viscosity testing of lubricants, fuel oils, hydraulic fluids, and crude oil
-
Quality control in refineries, petrochemical labs, and R&D
-
Conforms to test methods such as ASTM D445 / D446, ISO 3104 / 3105
