Key Features:
-
High-Quality Construction:
-
Heat-resistant glass vessel (85 mm diameter, 120 mm depth).
-
Brass rings – tapered design conforming to standard test method.
-
Standard steel balls (9.5 mm diameter) and ball centering guides for precision.
-
-
Optimized Design:
-
Support rings positioned horizontally with exact 50 mm depth below bath surface.
-
Distance of 25 mm between bottom plate and rings maintained for accuracy.
-
-
Advanced Heating System:
-
Microprocessor-based digital temperature controller with precise sensor.
-
Motorized stirrer for uniform heating.
-
-
Durable Body:
-
Made from 19 SWG, 304 AISI stainless steel with corrosion-resistant matt finish.
-
-
Certified Thermometers:
-
Supplied with ASTM 15C and ASTM 16C thermometers (with calibration certificate).
-
Technical Specifications:
-
Power Supply: 230 ±10% Volt AC, 1 Phase, 50 Hz
Why Choose Our Softening Point Apparatus?
-
Compliant with ASTM and IS standards for accurate softening point measurement.
-
Durable stainless steel construction ensures long life and reliability.
-
Digital temperature control for precision and ease of use.
