Key Features:
-
✅ Double-walled construction with inner cylindrical Dewar flask and outer metal casing
-
✅ Front toughened glass viewing window for safe visual access to bath interior
-
✅ Rear-mounted low wattage fluorescent lamp for excellent bath illumination
-
✅ Bakelite cover plate with openings for 2 viscometers
-
✅ CFC-free single or cascade refrigeration system with eco-friendly refrigerant
-
✅ Microprocessor-based PID controller with feather-touch keyboard and PT-100 sensor
-
✅ Motorized stirring system for optimal vertical and horizontal liquid circulation
-
✅ Temperature stability and uniformity of ±0.1°C
-
✅ Liquid bath capacity: 12 Litres
-
✅ Wide temperature range: from -72°C to +60°C
-
✅ Power Supply: 230 V AC, 1 Phase, 50 Hz
⚙️ Technical Specifications:
| Parameter | Specification |
|---|---|
| Temperature Range | –72°C to +60°C |
| Temperature Accuracy | ±0.1°C |
| Controller Type | PID Microprocessor-based with PT-100 sensor |
| Viscometer Capacity | 2 openings |
| Bath Volume | 12 Litres |
| Construction | Double-walled with cylindrical Dewar flask |
| Refrigeration System | CFC-free, Single or Cascade, Eco-friendly refrigerant |
| Stirring Mechanism | Motorized, horizontal and vertical circulation |
| Lighting | Rear-mounted low wattage fluorescent lamp |
| Power Supply | 230 V, 1 Phase, 50 Hz |
🧪 Applications:
-
Kinematic viscosity testing at sub-zero and ambient temperatures
-
Analysis of crude oils, engine lubricants, diesel fuels, and chemicals
-
Ideal for R&D, QA/QC, and compliance testing under ASTM and ISO standards
